Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
-
Fork
FX carbon, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR
-
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
-
Skewer front
139x5 mm bolt-on
-
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
-
Skewer rear
152x5 mm QR
-
Rim
Bontrager Tubeless Ready Disc, 32-hole, Presta valve
-
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
-
Shifter
Shimano CUES U6000 w/optical gear display, 10-speed
-
Rear derailleur
Shimano CUES U6000 GS
-
Crank
Size: S, XS, M Prowheel alloy, 40T narrow-wide ring, 170 mm length; Size: XL, L Prowheel alloy, 40T narrow-wide ring, 175 mm length
-
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
-
Chain
Shimano LG500
-
Pedal
Bontrager City pedals
-
Saddle
Bontrager H1
-
Seatpost
Size: S, XS, M Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length; Size: XL, L Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length
-
Handlebar
Size: S, XS, M Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 600 mm width; Size: XL, L Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 660 mm width
-
Grips
Trek Line Ergonomic Pro, lock-on
-
Stem
Size: S, XS Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length; Size: XL, L, M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
-
Brake
Shimano hydraulic disc, MT201 lever, UR300 calliper
-
Brake rotor
Shimano RT26, 6-bolt, 160 mm
-
Weight
M - 11.65 kg / 25.69 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
