Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
-
Fork
FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR
-
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
-
Skewer front
139x5 mm bolt-on
-
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
-
Skewer rear
152x5 mm QR
-
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
-
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
-
Shifter
Shimano U4000, 9-speed
-
Rear derailleur
Shimano CUES U4000
-
Crank
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
-
Bottom bracket
Sealed cartridge, 68 mm
-
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
-
Chain
Shimano LG500
-
Pedal
Bontrager City pedals
-
Saddle
Bontrager Sport
-
Seatpost
XS, S, M: Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
L, XL: Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length
-
Handlebar
XS, S, M: Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
L, XL: Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
-
Grips
Trek Line Ergonomic Comp, lock-on
-
Stem
XS, S, M: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
L, XL: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
-
Brake rotor
Tektro wave, 6-bolt, 160 mm
-
Brake Set
Tektro HD-R280 hydraulic disc, 160 mm rotor
-
Weight
M - 12.10 kg / 26.68 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
