Platform
Synapse Carbon
Model Name
Synapse Carbon 3 L
Model Code
C12303U
Frame
Synapse Carbon, SmartSense equipped, Proportional Response size-specific design, BSA threaded BB, flat mount brake, 12x142mm thru axle, thru-tube internal cable routing with Switch Plate, removable fender bridge, hidden rack/fender mounts
Fork
Synapse Carbon, integrated crown race, Proportional Response size-specific design, 12x100mm thru-axle, thru-tube internal routing, hidden fender mounts
Headset
Synapse Sealed Bearing, integrated, 1-1/4"-1-1/8"
Rear Derailleur
Shimano 105 7100, 12-speed
Front Derailleur
Shimano 105 7100, braze-on
Shifters
Shimano 105 7100, 12-speed
Chain
Shimano 105 7100, 12-speed
Crank
Shimano RS520, 50/34
Rear Cogs
Shimano 105 7100, 12-speed, 11-34
Bottom Bracket
Shimano BSA
Brakes
Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors
Brake Levers
Shimano 105 7100, 12-speed
Rims
RD 2.1, 28h, 21mm inner width
Spokes
Stainless Steel, 14g
Tire Size
30
Wheel Size
700
Hubs
(F) Formula cartridge bearing, 12x100mm centerlock / (R) Formula cartridge bearing, 12x142mm centerlock
Tires
Vittoria Zaffiro Pro Reflective, 700x30c
Handlebar
Cannondale 3, 6061 Alloy, Compact
Stem
Cannondale 3, 6061 Alloy, 31.8, 7°
Grips
Fabric Knurl Bar Tape
Saddle
Fizik Aliante Delta, S-alloy rails
Seatpost
Cannondale 3 SmartSense, 6061 Alloy, 27.2x350mm (48-56), 400mm (58-61)
Wheel Sensor
Cannondale Wheel Sensor
Extra 1
SmartSense with Lights, Trainer-compatible thru-axle
