Frame
Ransom 24"/26" Alloy 6061 Custom butted tubingTapered headtube, BB73Internal cable routingUDH 148x12mm
-
Fork
X-Fusion Slant RC 26, 140mm, taperedKids' Bike Tune
-
Rear Shock
X-Fusion 02Pro R TrunnionRebound Adjuster, Kids' Bike TuneTravel 130mm, 165x45mm
-
Rear Derailleur
SRAM NX 11 Speed
-
Shifters
SRAM NX Trigger
-
Crankset
Prowheel DMJ 30T 2PCBoost CL:52, 127mm
-
BB-Set
Prowheel BB73
-
Chain
KMC X11
-
Cassette
SRAM, PG-1130, 11-42T, 11-Speed
-
Brake Levers
Shimano BL-UR405
-
Brakes
Shimano BR-MT410
-
Rotor
Shimano Deore SM-RT56, IS, F: 180 R: 160
-
Handlebar
LEADTEC Kids riser bar alloy DB, 31.8mm clamp, 580mm, BS 9°Syncros Grip Kids D19mm, Lock-on
-
H'stem
LEADTEC, 40mm, -/+7°31.8mm clamp
-
Seatpost
Syncros Dropper Ducan Remote31.6mm, 80mm, Kid centric custom tune
-
Seat
Syncros Future Pro
-
Headset
Syncros OE Press Fit, Reduce 1.5"-1 1/8"OD 50/62mm, ID 44/56mm
-
Hub (Front)
Formula DC-71 IS, 15x100mm
-
Hub (Rear)
Formula DC-3248 IS, Boost 12x148mm
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Syncros DP30, 32H, 30mm
-
Front Tire
Kenda Hellkat K1201, 60TPI, folding, 24x2.4
-
Rear Tire
Kenda Hellkat K1201, 60TPI, folding, 24x2.4
-
Pedals
Feimin FP-803
-
Approx weight in KG
13.4
-
Approx weight in LBS
29.54
-
Max. System Weight
80kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
