Frame
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
-
Fork
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
-
Steerer tube
FSA 1-1/2" Integrated Aluminium Cup
-
Battery
Mahle iX350 36V 353Wh
-
Motor
Mahle motor hub X20, ALC
-
Display
Mahle Pulsar One monochrome ANT+ LEV
-
CHARGER
Mahle Active Charger up to 4A
-
Remote
Mahle ONE Head Unit (BT/ANT+)
-
Crankset
Shimano 105 R7100 34x50t
-
Shifters
Shimano R7120
-
Cassette
Shimano 105 R7100 11-34t 12-Speed
-
Rear derailleur
Shimano 105 R7100
-
Front derailleur
Shimano 105 R7100
-
Chain
Shimano M6100
-
Handlebar
OC Road Performance RP21 Alu SL, Reach 80, Drop 125
-
Stem
OC Road Performance RP10, -8º
-
Brakes
Shimano R7170 Hydraulic Disc
-
Wheels
Alloy, Tubeless, 700c, 21c
-
Tyres
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
-
Front Wheel Axle
Orbea Thru Axle 12x100mm M12x2 P1 Lite
-
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12x2 P1 Lite
-
Seatpost
OC Performance XP10-S Carbon, 27.2mm, Setback 20
-
Saddle
Fizik Aliante R5
-
Front light
Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
-
Rear light
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
-
Handlebar Tape
Orbea Anti-Slippery/Shock Proof
